| Size Range |
TOTAL TOLERANCE |
OVALITY TOLERANCE |
CASING DIMENSIONS |
IN : 004 .010
MM: .1016 .2540 |
IN : .00005
MM: .00127 |
IN : .00003
MM: .00076 |
IN :1.0 OR 1.25* .312
MM: .25 OR 28* 8 |
IN : .0101 — .020
MM: .2541 .5080 |
IN : .000075
MM: .0019 |
IN : .00004
MM: .00102 |
IN : .1.0 OR 1.1258 .312
MM: 25 OR 28* 8 |
IN 1 .0201 .040
MM: .5081 1.016 |
IN : .0001
MM: .00254 |
IN : .00006
MM: .0015 |
IN 11.0 OR 1.125* . 375
MM: .25 OR 28* 10 |
IN : .0401 — .060
MM: 1.0161 1.524 |
IN : .000125
MM: .00318 |
IN : .00O08
MM: .0020 |
IN : .1.0 OR 1.125* .375
MM: 25 OR 28* 10 |
IN : .0601 .090
MM: 1.5421 2.286 |
IN : .000150
MM: .0038 |
IN : .0001
MM: .00254 |
IN :1.0 OR 1.125* 500
MM: .25 OR 28* 10 |
IN : .0901 .120
MM: 2.2861 3.048 |
IN : .000175
MM: .00445 |
IN : .000125
MM: .00318 |
IN 11.0 OR 1.125* .625
MM: 28 OR 28* 15 |
IN : .1201 .240
MM: 3.0481 6.096 |
IN : .0002
MM: .0051 |
IN : .00015
MM: .0038 |
IN :1.5* .875
MM: 43* 27 |
IN : .2401 .360
MM: 6.0961 9.144 |
IN : .00025
MM: .0063 |
IN : .000175
MM: .00445 |
IN :1.5*.875
MM: 43* 27 |
IN : .3601 @ LARGER
MM: 901441 & LARGER |
IN : .0003
MM: .0076 |
IN : .0002
MM: .0051 |
IN :1.5*.875
MM: 43* 27 |
